SICK KTML Series - 6 Commissioning; Sensitivity

6 Commissioning
6.1 Sensitivity
Light spot dimensions
Sensor
Ø 2.2
(0.09)
Ø 1.7
(0.07)
Ø 1.1
(0.04)
20
(0.79)
50
(1.97)
80
(3.15)
Figure 3: Line spot dimensions in mm (inch), 50 mm version
Ø 1.2
(0.05)
Ø
1.8
(0.07)
Ø 2.4
(0.09)
220
(8.66)
250
(9.84)
280
(11.02)
Sensor
Figure 4: Line spot dimensions in mm (inch), 250 mm version
Please note the differences in the sensitivity at different sensing ranges.
140
120
100
8
0
60
40
20
20
(0.79)
30
(1.18)
40
(1.57)
50
(1.97)
60
(2.36)
70
(2.76)
80
(3.15)
90
(3.54)
0
0
Distance [mm]
%
Figure 5: KTML 50 mm version
