SICK KTS Core - Technical Data; General Data

11 Technical data
11.1 General data
Table 18: Technical data
Attribute Value
Sensing distance
1
13 mm
Sensing distance tolerance ±3 mm
Light spot size/light spot
direction
Longitudinal:
3.9 mm x 1.1 mm
Supply voltage
2
10.8 V – 28.8 V
Current consumption
3
< 100 mA
Switching frequency 12.5 kHz
1-point teach-in (color mode): 4 kHz
Response time 40 µs
1-point teach-in (color mode): 120 µs
Jitter 20 µs
1-point teach-in (color mode): 60 µs
Switching mode PNP or NPN or push/pull
Switching output (Q) PNP: HIGH = U
V
–3 V/LOW = 0 V
NPN: HIGH = U
V
/LOW ≤ 3 V
Push/pull: HIGH = V
s
- 3 V/LOW ≤ 3 V
Teach-in input (ET)
U
V
≥18 V
PNP and push/pull:
Teach: U > 15 V
Run: U < 5 V
NPN:
Run: U > 15 V
Teach: U < 5 V
Teach-in input (ET)
U
V
< 18 V
PNP and push/pull:
Teach: U > 0.83*U
V
Run: U < 0.28*U
V
NPN:
Run: U > 0.83*U
V
Teach: U < 0.28*U
V
Initialization time < 150 ms
Enclosure rating IP67
Ambient temperature
(operation)
-20 °C … +60 °C
Ambient temperature (UL) max. 60 °C
Ambient temperature
(warehouse)
-25 °C … +75 °C
Protection class III
Circuit protection U
V
connections, reverse polarity protected, output Q short-circuit
protected, interference-pulse suppression
Max. output current of the
switching output
4
100 mA
1
From leading edge of lens
2
Operation in short-circuit protected network max. 8 A
3
Without load
4
Sum current of all digital outputs
11 TECHNICAL DATA
34
O P E R A T I N G I N S T R U C T I O N S | KTS Core 8026298/2021-08-11 | SICK
Subject to change without notice
