SICK LMS100 - Special features of the LMS1 xx

Product description
20 © SICK AG · Germany · All rights reserved · Subject to change without notice 8012471/ZN27/2017-06-09
Operating Instructions
LMS1xx Laser Measurement Sensors
Chapter 3
3.4 Special features of the LMS1xx
LMS12x/LMS13x/LMS14x Security and LMC12x/LMC13x VdS (object protection) 
You will find further information on the special features of these devices in the document
”Technical Information (installer instructions VdS)”, part no.: 8013749, issue in English.

Please see section 1.5 “Further information” on page 9.
Variant Special features
All  Field of view maximum 270°
 Resolution of the angular step width: 0.25/0.50°
 Scanning frequency 25/50 Hz
 Flexible system configurations
 Configuration/measured value request using telegrams (command strings)
 2 digital switching inputs
 Data interfaces Ethernet, RS-232, CAN (for the connection of an I/O module)
Measured value output (raw data)
 electro-sensitive, active measurement technique
 measurement of objects with almost any shape
 measured value output for a second reflection pulse (e.g. in rain or on measurement through a window)
Integrated field application
 Up to 10 configurable evaluation fields (depends on LMS1xx variant)
 Monitoring of the evaluation field contours
 Switching of the evaluation fields using digital switching inputs
 Encoder inputs (not for LMS12x/LMS13x/LMS14x)
 Additional output of the evaluation field (unoccupied or infringed) via switching outputs or telegrams
LMS10x  Scanning range up to 20 m with > 13 % object remission (18 m with 10 % object remission)
 Indoor housing with protection class IP 65
 3 digital switching outputs
LMS11x  Scanning range up to 20 m with > 13 % object remission (18 m with 10 % object remission)
 Outdoor housing with protection class IP 67
 3 digital switching outputs
LMS12x
LMS173
 Scanning range up to 20 m with > 13 % object remission (18 m with 10 % object remission)
 Indoor housing with protection class IP 65
 Optimized for usage in object protection systems
 2 additionally digitale switching inputs
 Relay switching outputs
 Digital sabotage output
LMS13x
LMS182
Like LMS12x, however
 Outdoor housing with protection class IP 67
LMS14x Like LMS12x, however
 Scanning range up to 30 m with > 10 % object remission
 Outdoor housing with protection class IP 67
 Optimized for usage in object protection systems
 Relay switching outputs
LMS14x Core: the device sends the measured contour values via RS-232/Ethernet only with low refresh rate. The
data can only be used for visualization and configuration on the PC.
LMS15x Like LMS11x, however
 Scanning range up to 50 m with > 75 % object remission (18 m with 10 % object remission)
Tab. 9: Special features of the LMS1xx variants
