Commissioning and configuration
82 © SICK AG · Germany · All rights reserved · Subject to change without notice 8012471/ZN27/2017-06-09
Operating Instructions
LMS1xx Laser Measurement Sensors
Chapter 7
7.3.1 Connect the data interfaces
Connect PC and LMS1xx together as per table.
7.3.2 Starting SOPAS ET and opening the scan assistant
1. Start SOPAS ET.
By default SOPAS ET opens the program window with the English user interface.
2. To change the language setting, in the start dialog box click CANCEL and using the menu
T
OOLS, OPTIONS change the language for the user interface to GERMAN/DEUTSCH.
3. If the language setting has been modified, quit SOPAS ET and re-start.
4. In the dialog box, choose the option CREATE NEW PROJECT and confirm with OK.
5. In the main window in SCAN ASSISTANT click the CONFIGURATION button.
The SCAN ASSISTANT dialog box appears.
7.3.3 Configuring the serial connection
1. In the SCAN ASSISTANT dialog box, under SERIAL CONNECTION, STANDARD PROTOCOL, activate the
A
CTIVATE SERIAL COMMUNICATION checkbox.
2. Click ADVANCED... button.
3. In COLA DIALECT choose the BINARY option.
4. Choose following PORT SETTINGS: 8 data bits, no parity, 1 stop bit.
5. Confirm the settings with OK.
The ADVANCED SCAN SETTINGS dialog box is closed.
6. Confirm the settings in the SCAN ASSISTANT dialog box with OK.
The SCAN ASSISTANT dialog box is closed.
7.3.4 Configuring the Ethernet connection
Important Deactivate all programs on your PC/notebook that access Ethernet or TCP/IP.
1. In the SCAN ASSISTANT dialog, under INTERNET PROTOCOL, IP COMMUNICATION, select the
A
CTIVATE IP COMMUNICATION checkbox and the USE AUTOIP checkbox.
2. Confirm the settings in the SCAN ASSISTANT dialog box with OK.
The SCAN ASSISTANT dialog box is closed.
Data interface Comment
Ethernet Connect the PC to the LMS1xx using the Ethernet cable (see Fig. 47 on
page 73)
Or:
RS-232 Connect the PC (serial interface) to the LMS1xx (see Fig. 46 on page 73)
Tab. 34: Connect the data interfaces
