NOTE
For information, see the telegram listing on the product page.
The call is made via the SICK Product ID: pid.sick.com/{P/N}/{S/N}
{P/N} corresponds to the part number of the product (see type label).
{S/N} corresponds to the serial number of the product (see type label).
Table 4: Address assignment method
Scan layer DINISO8855 Physical
1 22.7° -22.7°
2 17.6° -17.6°
3 12.5° -12.5°
4 7.51° -7.51°
5 2.5° -2.5°
6 (high resolution) 0° 0°
7 -2.4° 2.4°
8 -7.3° 7.3°
9 -12.8° 12.8°
10 -17.3° 17.3°
11 -21.9° 21.9°
12 -26.7° 26.7°
13 -31.9° 31.9°
14 (high resolution) -35.4° 35.4°
15 -37.2° 37.2°
16 -42.8° 42.8°
3 PRODUCT DESCRIPTION
