SICK SIM1000 FXA - Product Description; Device View

3 Product description
3.1 Device view
1
2
3
Figure 1: SIM1000 FXA
1
Connections for switching input/output, IO-Link, CAN, and voltage supply
2
Serial connections or encoder connection
3
Ethernet connections
1
3
2
4
Figure 2: SIM1000 FXG
1
Connections for switching input/output, IO-Link and CAN
2
FLEXBUS+ connection (includes voltage supply)
3
Serial connections or encoder connection
4
Ethernet connections
PRODUCT DESCRIPTION 3
8023299/1BLK/2021-07-28 | SICK O P E R A T I N G I N S T R U C T I O N S | SIM1000 FXA, SIM1000 FXG
