Chapter 3 Operating Instructions
UE402
10 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009874/YT67/2016-02-22
Subject to change without notice
Product description
3 Product description
T
his chapter provides information on the special features and properties of the UE402. It
describes the construction and the operating principle of the device, in particular the dif-
ferent operating modes in connection with the safety light curtain C4000.
Please read this chapter before mounting, installing and commissioning the device.
The functions of the UE402 can only be used in conjunction with the C4000 safety light
curtain Standard or C4000 Advanced with the following entry on the type label in the field
Software version: 3.0.0 or later.
3.1 Special features
The switching amplifier UE402 extends the application possibilities of the safety light
curtain C4000:
6 operating modes are predefinable (see page 18)
PSDI mode (see page 12)
protective field evaluation bypass (see page 11)
teach-in mode: Adjusting the blanked-out areas directly on the device through the
corresponding objects in the protective field (C4000 Advanced only, see page 17)
3.2 Operating principle of the device
3.2.1 Principle of the device
The UE402 is an electronic module. It processes certain signals of the safety light curtain
C4000 or the cascading C4000 and merges them with the signals of other connected
systems. These systems may include:
an operating mode selector switch
a teach-in key-operated switch
a key-operated pushbutton for bypass
machine cycle contacts, e.g. for the top and bottom dead centres of a press
The UE402 is usually installed in the control cabinet.
3.3 Configurable functions
This chapter describes the functions of the safety light curtain C4000 which are selectable
via software, which can only be used in connection with switching amplifier UE402. The
functions can be partially combined with the other configurable functions of the safety light
curtain.
Test the protective device after any changes!
Each time the configuration is changed you must test the effectiveness of the entire pro-
tective device (see chapter titled “Test notes” in the operating instructions of the safety
light curtain C4000).
Note
WARNING
