Product description
3.4.2 Functions that cannot be combined
Several functions of the safety light curtain C4000 cannot be combined.
You can configure two functions, each of which are applicable within one operating mode,
in two different operating modes of the same application, even if Tab. 3 indicates that they
cannot be combined.
Configurable function Limitation
Teach-in key-operated
s
witch on the extension
connection
Not with the Emergency Stop on the C4000
Teach-in key-operated
switch on the UE402
Not with Bypass
Emergency stop Not with the teach-in key-operated switch on the
extension connection of the C4000
Bypass Not with PSDI mode
Not with PSDI window
Not with the teach-in key-operated switch on the UE402
PSDI mode Not with Bypass
Not with fixed blanking with increased size tolerance
Not with floating blanking with partial object monitoring
Not, if the effective resolution is > 30 mm (EN 692)
PSDI window Not with Bypass
Not with fixed blanking with increased size tolerance
Not with floating blanking
Not with reduced resolution
Reduced resolution
(effective resolution
> 30 mm)
Not with fixed blanking with increased size tolerance
Not with floating blanking with partial object monitoring
Not with PSDI mode
Not with PSDI window
Floating blanking with
partial object monitoring
Not with fixed blanking with increased size tolerance
Not with reduced resolution
Not with PSDI mode
Not with PSDI window
Fixed blanking with
increased size tolerance
Not with floating blanking with partial object monitoring
Not with reduced resolution
Not with PSDI mode
Not with PSDI window
N
ote
cannot be combined
