Technical specifications
9 Technical specifications
9.1 Data sheet
Minimum Typical Maximum
General system data
Type Type 4 (IEC 61496>1)
Safety integrity level
1)
SIL3 (IEC 61508)
SIL claim limit
1)
SILCL3 (EN 62061)
Category Category 4 (EN ISO 13849>1)
Performance Level
1
)
PL e (EN ISO 13849>1)
PFHd (mean probability of a
dangerous failure per hour)
System figures including the safety light curtains.
The figures for the safety light curtains do not need
to be added to these system figures.
C4000 Standard/
C4000 Advanced
Host 15× 10
–
9
Host/guest/guest (14 mm,
30 mm)
32× 10
–9
Host/guest/guest (20 mm,
40 mm)
63× 10
–9
C4000 Entry/Exit 15× 10
–9
C4000 Palletizer/C4000 Fusion 15× 10
–9
T
M
(mission time) 20 years (EN ISO 13849>1)
Protection class III (EN 61140)
Enclosure rating IP 20 (IEC 60529)
Supply voltage U
V
at the UE402
2)
19.2 V 24 V 28.8 V
Residual ripple
3)
± 10%
Power consumption 110 mA
Power-up delay after connecting
the supply voltage
0.5 s 4 s
Housing dimensions See “Dimensional drawing” on page 35.
Weight 120 g
1)
For detailed information on the exact design of your machine/system, please contact your local SICK
representative.
2)
The external voltage supply must be capable of buffering brief mains failures of 20 ms as specified in
EN 60204-1. Suitable power supplies are available as accessories from SICK (Siemens type series 6 EP 1).
3)
Within the limits of U
V
.
Tab.
10
:
Technical data
UE402
