SICK UE402 - Inputs In A1 to A6, MCC-BDC and MCC-TDC; Inputs In B1 and In B2, outputs Out B1 and Out B2; Operating data

Chapter 9 Operating Instructions
UE402
34 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009874/YT67/2016-02-22
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Inputs In A1 to A6, MCCDBDC and MCCDTDC
Switching voltage
4
)
HIGH 11 V 24 V 30 V
Input current HIGH 6 mA 10 mA 20 mA
Switching voltage
4)
LOW –30 V 0 V 5 V
Input current LOW –3 mA 0 mA 0.5 mA
Changeover time operating modes
In A1 to In A6
150 ms 2 s
Bouncing time of the contacts 25 ms
Inputs In B1 and In B2, outputs Out B1 and Out B2
Cable resistance 30 
Cable capacitance 10 nF
Bouncing time of the contacts 25 ms
Bypass function
Changeover time 2 s
Latency time 150 ms
Operating data
Cable length
5)
for the C4000 50 m
Wire cross-section 0.25 mm² 2.5 mm²
Ambient operating temperature 0°C +55°C
Air humidity (non-dewing) 15% 95%
Storage temperature –25°C +70°C
Rigidity 5 g, 10–55 Hz acc. to IEC 60068-2-6
Shock resistance 10 g, 16 ms acc. to IEC 60068-2-29
4)
As per IEC 61131-2.
5)
Depending on load, power supply and wire cross-section. The technical specifications must be observed.
