Chapter 3 Operating Instructions
UE402
18 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8009874/YT67/2016-02-22
Subject to change without notice
Product description
3.4 Operating modes
Y
ou can configure up to six operating modes with the aid of the CDS. The operator can
switch between these operating modes by means of an operating mode selector switch.
This section describes the scope of the configured functions and the possibilities for com-
bining them.
The operating mode selector switch must be a key-operated switch.
You can also set up fewer than six operating modes.
No electrical connection may be made for operating modes that are not in use.
Otherwise the safety light curtain will be completely blocked (lock-out).
Check the protective device in every operating mode and after every change!
If you configure several operating modes, you must especially check the operation of the
protective device in each of these operating modes. To this end, you must observe the test
notes in the operating instructions of the safety light curtain C4000.
Device symbol C4000 Host (receiver), context menu Configuration draft, Edit, area
Operating modes. You can find more information on setting up and storing an operating
mode in the C4000 online help in the CDS.
The connection of the operating mode selector switch is described in chapter 5.2
“Operating mode selector switch” on page 25.
Notes
WARNING
