SICK WLL80 Analog - Product Description; Product Identification

4 Product description
4.1 Product identification
Type label
D-79183
Waldkirch,
Germany
6076723
21XX0001H
DID8389244
WLL80P-22T6Y1DZA71Z1Z1
BN
:
1- L+
12...30V DC, Class 2
BU
:
3- M
0V
BK
:
4- Q1/C
OUT
WH
:
2- Q2
Enclosure Type1 MADE IN CHINA
0.1A
<
_
_
OUT
0.1A / MFin
<
1 2
4
5 3 6
Figure 1: Side view of WLL80 with label details
1 Pin assignment
2 Electrical data and environmental data
3 Date of manufacture
4 Type code of device
5 Part number
6 2D code
Logos/approvals
Figure 2: Side view of WLL80 with logos
