8.11 Initializing the device
8.11.1 Navigation tree for initialization (SB)
Table 62: Navigation tree for initialization
1
A
|
SB
Reset
Initialisieren
OK
ESC
SB
Select initialization using and confirm using OK. After confirmation,
the display in the menu returns to the initial settings.
1
A
|
Appl. Reset
SB
Application reset
Resets all parameters to factory
settings except the stored job
parameter sets
1
A
|
Factory reset
SB
Factory settings reset
Completely resets the device incl.
job parameter sets to the factory
settings
Table 63: Factory settings
Setting Value
Det. mode (Detection mode) Pushbuttons
Invert output (Invert output signal) Not invert. (not inverted)
Response time 250µs
Language (display) English
Indicator mode (display) Digits
Brightness (display) 50%
Turn display (display) Off
Inversion (display) Off
Display alerts (display) Off
Zeroing (display value) Deactivate
Save energy Off
Timer mode (time function) Deactivated
Time setting(time1) 1ms
Time setting(time 2) 1ms
Hysteresis 5%
Switch. point mode (Switching point mode) Single/window
SPC (Sender Power Control) On
AutoAdapt Off
Sender power Max. (maximum sender power)
Counter mode Off
Compare value (count compare value) 10
Counter value 0
Edge direct. (Edge direction) Pos + neg (both edge directions)
Edge offset 12,500µs (50 cycles x response time 250µs)
Edge hyst. (Edge hysteresis) 5 (digits)
