38
SOLITE PRO SOLITE PRO LOW
Product code SOLITE/PRO SOLITE/PRO/LOW
Product code (with battery backup) SOLITE/PRO/BB SOLITE/PRO/LOW/BB
Overall length 2230mm
Overall width
(without side rail channels fitted)
1005mm
Overall width
(with side rail channels fitted)
1055mm
Mattress platform height 395 - 815mm 295 - 715mm
Under bed clearance
(to underside of frame when bed is lowered)
340mm 245mm
Under bed clearance
(to underside of actuator when bed is lowered)
195mm 100mm
Mattress platform length 2010mm
Mattress platform length (extended) 2175mm
Mattress platform width 945mm
Foot down tilt* 0 - 12°
Mattress platform angles (max)
Safe working load 226 kg (35½ stone)
Maximum patient weight 191 kg (30 stone)
Product weight
(on transport stand)
85 kg
Part
weights
Leg section 20.5 kg
Backrest 24.5 kg
Bed ends (each) 18.5 kg
Application environment 3 & 4
Shock and vibration
To be used on a flat level floor
(e.g. vinyl/carpet/laminate based)
UV Intended for indoor use only
16. SPECIFICATION
16.1 Bed Data
*
As standard, the handset provided omits the head down tilt (Trendelenburg)
function for safety reasons. If Trendelenburg function is required, a replacement
handset can be purchased featuring this function. Please refer to section 18 for
the part code, and to the contact information in section 2 to order or to request
further information – Sidhil recommend the use of the standard handset when
the bed is being used in a domestic environment.
• The Solite Pro Low does not meet the upper height requirements of IEC 60601-
2-52:2009, if patient requirements are such that the height range is deemed to
pose a potential hazard the Solite Pro should be used instead, please refer to the
contact information in section 2 to request further information.
72°
21°
26°
Warning
