Siegenia GENIUS 2.2 PANIC - Feedback Function

02.202014/28 H47.ELEKS014EN-00

GENIUS 2.2 PANIC, Electromechanical mul-point lock
 
The feedback funcon provides informaon on the status of the selected funcons via an output contact (e. g.
door closed and locked). This makes a potenal-free switching output available for third party systems (e. g. alarm
systems).
The following values can be set in the menu "terminal 7 feedback funcon":
 LED 
(Funcon A)
Door closed and locked (standard value)
Funcon B
• In day mode -> door closed
• In night mode -> door closed and locked
Funcon C
Latch drawn
Funcon D
• Acve error
• Latch drawn or mul-point lock in locking or unlocking process
• Locked
• Not locked
Funcon E
Unlocked
Funcon F
Not released
 




LED 
1
8 s
Magenta Retrieve menu sengs
2 1 x 1 s
Yellow Change to menu „Terminal 7 feedback funcon“
3 3 s
(Example)
Display of the current set values
(Default value: funcon A)
4 (X) x 1 s
to
Yellow/
White
Yellow/
Magenta
Changing the values to the desired value:
funcon A to funcon F
5
3 s
(Example) Select value, save and exit menu





(Funcon A)
Funcon B
Funcon C
Funcon D
Funcon E
Funcon F
