Siegenia GENIUS 2.2 PANIC - Cylinder Operated Lock

17/2817/2802.2020H47.ELEKS014EN-00

GENIUS 2.2 PANIC, Electromechanical mul-point lock
 
For special variants of GENIUS (e. g. GENIUS 2.2 PANIC with funcon B) or for locks without a main lock case, the
funcon must be set to "Inacve" in the menu item "Latch in cylinder operated lock".
The following values can be set in menu "Latch in cylinder operated lock":
 LED 
(Acve)
Adjustment for latches with motorised latch retracon
Inacve
Adjustment for latches without latch retracon
 




LED 
1
8 s
Magenta Retrieve menu sengs
2 4 x 1 s*
Orange Change to menu „Latch in cylinder operated lock“
3 3 s
(Example)
Display of the current set values
(Default value: acve)
4 (X) x 1 s
to
Orange/
White
Orange/
Black
Changing the values to the desired value:
Acve and inacve
5 3 s
(Example) Select value, save and exit menu






(Locking
bolt)
N/C contact
