Connection
6.2 Electrical connection
1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b
33
Current-carrying capacity for power and signal cables
The current-carrying capacity of PVC/PUR-insulated copper cables is specified for routing
types B1, B2, and C under continuous operation conditions in the table with reference to an
ambient air temperature of 40°C. For other ambient temperatures, the values must be
corrected by the factors from the "Derating factors" table.
Table 6- 1 Cable cross-section and current-carrying capacity
Cross-section Current-carrying capacity rms; AC 50/60 Hz or DC for routing type
[mm
2
] B1 [A] B2 [A] C [A]
Electronics (to EN 60204-1)
0.20 - 4.3 4.4
0.50 - 7.5 7.5
0.75 - 9 9.5
Power (to EN 60204-1)
1,50 13,5 13,1 15,2
2,50 18,3 17,4 21
4 24 23 28
6 31 30 36
10 44 40 50
16 59 54 66
25 77 70 84
35 96 86 104
50 117 103 125
70 149 130 160
Table 6- 2 Derating factors for power and signal cables
Ambient air temperature [°C] Derating factor to EN 60204-1, table D1
30 1.15
35 1.08
40 1.00
45 0.91
50 0.82
55 0.71
60 0.58
