1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b
39
Commissioning
7
7.1 Measures prior to commissioning
Before commissioning the system, check that it is properly installed and connected. The
drive system must be commissioned as described in the operating instructions for the
converter/inverter.
Note
This list below does not claim to be complete. It may be necessary to perform additional
checks and tests in accordance with the specific situation on-site.
DANGER
Risk of electric shock!
When commissioning/operating electric motors, parts of the motor are always at a
dangerous voltage. If this motor is not correctly handled/operated, this can result in death or
severe personal injury as well as significant material damage. All of the warning information
on the product must be carefully observed!
WARNING
Danger from rotating rotor.
Provide touch protection for output elements.
Mechanical connection
Make sure that:
● Touch protection measures are in place for moving and live parts.
● The motor has been assembled and aligned properly.
● The rotor can spin without coming into contact with other parts and components.
● The operating conditions correspond to the data specified on the rating plate.
● All fixing screws, connecting elements, and electrical connections are tight and have
been attached properly.
● The output elements have the proper setting conditions according to type, for example:
– Couplings are aligned and balanced.
– The belt tension is properly adjusted if a belt drive is used.
– Gear tooth flank play and gear tooth tip play as well as radial play are properly
adjusted if a gear drive is used.
