Assembling
4.3 Disassembling the device
3TK2810-1 safety-related speed monitor
32 System Manual, 01/2011, 926246402000 DS 02
Disassembling the device from a level surface
Step Operating instruction Figure
1 Hold the device firmly.
2 Unscrew the cap screws.
3 Lift the device from the level surface.
4 Remove the securing brackets from the
device.
