Siemens 6ES7134-4FB51-0AB0 - 1 Properties

2AI U HS analog electronic module (6ES7134-4FB51-0AB0)
Manual, 04/2007, A5E01076015-01
7
Properties
1
1.1 2AI U HS analog electronic module (6ES7134-4FB51-0AB0)
Properties
● 2 inputs for measuring voltage
● Input ranges:
±
10 V, resolution 13 bits + sign
± 5 V, resolution 13 bits + sign
± 2.5 V, resolution 13 bits + sign
1 V to 5 V, resolution 13 bits
● Isolated from the load voltage L+
● Permissible common mode voltage 100 VAC
SS
● Supports isochronous operation
– Minimum time for the synchronous DP cycle (T
DPmin
): 2.5 ms
– Minimum conversion time of the input modules (T
WEmin
): 1.1 ms
General terminal assignment
Note
Terminals 4, 8, A4, A8, A3 and A7 are only available at specified terminal modules.
Terminal assignment for 2AI U HS (6ES7134-4FB51-0AB0)
Terminal Assignment Terminal Assignment Notes
1 M
0+
5 M
1+
2 M
0-
6 M
1-
3 M
ana
7 M
ana
4 n.c. 8 n.c.
A4 AUX1 A8 AUX1
A3 AUX1 A7 AUX1
• M
n+
: Input signal "+", Channel n
• M
n-
: Input signal "-", Channel n
• M
ana
: Ground of the module
• n.c.: Not connected (max. DC 30 V can be connected)
• AUX1: Protective-conductor terminal or potential bus (freely usable
up to 230 VAC)
