10.3 Technical specifications of the IM 153-x
ET 200M
Operating Instructions, 04/2022, EWA-4NEB7806006-09
231
Technical Specifications
IM 153-1
IM 153-2
IM 153-2 FO
• Number of digital input signals
—
Max. 32 per slot
Max. 128
Max. 128
• Message buffer
—
15 message buffers with in each case max. 20 messag-
es
• Time interval for sending the
message buffers when there is a
message
—
1 s
• Time stamping
—
• Per digital input
• Per digital input module
• total ET 200M
•
Time stamp in the case of
—
rising / falling edge as incoming or outgoing signal
• Time format
—
RFC 1119 Internet (ISP)
Voltages, currents, electrical potentials
Rated voltage
DC 24 V (DC 20.4 to 28.8 V)
Current consumption at 24 V
Max. 350 mA
Max. 550 mA
Max. 500 mA
max. 600 mA (for
IM 153-2BAx2)
Inrush current
2.5 A
2.5 A (for IM 153-2AA0x
and IM 153-2BA00)
3.5 A
3.5 A (for IM 153-2BAx1)
3.0 A (for IM 153-2BAx2)
Power on the I/O bus
(to supply the I/O modules)
—
max. 1.5 A
—
I
2
t
0.1 A
2
s
Recommended external fusing for
supply lines
In a configuration with grounded reference potential a fuse is required for redun-
dant interface modules (recommendation: 2.5 A).
Power dissipation, type
3 W
5 W (for IM 153-2AA0x
and IM 153-2BA00)
4.5 W (for IM 153-2AB0x
and IM 153-2BB00)
4 W (for IM 153-2BAx1)
5.5 W (for IM 153-2BAx2)
