Installation
118/214 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DA10 • 861-9601.9
➭ Clean the silicone adapter and the outside-cone bushing carefully. Use a cleaning agent
without solvents and a lint-free cloth.
➭ Protect the connection socket of the voltage transformer against damages and pollution
using a suitable cover.
➭ For voltage tests: Close the outside-cone bushing at the busbar housing with a surge-proof
cap, and protect it against damages and pollution.
CAUTION
Voltage transformer falling down
Can cause injury and property damage.
While being removed from the bushing, the voltage transformer can detach suddenly.
➭ Remove the voltage transformer upwards as uniformly as possible.
➭ Adequately support the voltage transformer so that it cannot fall as it is being withdrawn.
➭ Do not use excessive force.
WARNING
Risk of injury while transporting the voltage transformer
The voltage transformer may fall down during transport. Serious injury and property
damage can be the consequence.
➭ Secure the voltage transformer against falling down. If required, use a support.
➭ If necessary, transport the voltage transformer with several persons or with suitable aids.
INFORMATION
While removing the voltage transformer, the silicone adapter may fall out of the voltage
transformer.
➭ Keep the silicone adapter carefully for later use.
