6 General
ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG
01.05 CS SD 24
Page 6 of 46
Medical Solutions
WARNING
Electrical voltage!
Noncompliance can lead to death, physical injury or property dam-
age.
¹ After completing service work and reattaching all covers,
a ground wire test must be performed according to
ARTD-002.731.17.. . The ground wire resistance must not
exceed 0.2 ohms.
WARNING
Electrical voltage!
Noncompliance can lead to death, physical injury or property dam-
age.
¹ The electrolytic capacitor batteries of the generator and
on the generator boards remain charged even after the
system has been switched off for a longer period of time.
These electrolytic capacitors must be discharged before
beginning work on the electrolytic capacitor batteries or
on the generator. To do this, set switch D21.S2 to the
UZ_OFF position and wait until LEDs D21.X22 and
D21.X23 extinguish. Then check the voltage between
measuring points X109.UZ_IST(ACT) and
X109.ANA_GND. This voltage must equal < 0.2V (corre-
sponding to Uz < 20V).
WARNING
Danger of pathogen infection!
Noncompliance can lead to death or physical injury.
¹ Since this product has been approved for use in operat-
ing rooms, it may be contaminated with infectious blood
or other excreta.
¹ Avoid any skin contact with blood or other excreta!
¹ The preventive measures against infectious diseases
specified in ARTD-002.731.37... must be strictly observed
at all times!
