Siemens ARCADIS Orbic Installation And Startup

20 3D Reconstruction Upgrade Part 1
ARCADIS Orbic SPR2-320.814.02.01.02 Siemens AG
01.05 CS SD 24
Page 20 of 46
Medical Solutions
• Attach the two limit switches at the cable module using M4 x 8 screws, washers and
contact washers (Fig.9/p.19)/(Fig. 10 / p. 19)/(Fig. 11 / p. 20).
Fig. 11: Limit switch with cabling
Fig. 12: Setting the limit switch
Setting the limit switches 0
• Manually move the C-arm into the end position.
