Operating Manual - Elevator Door Operation AT18
53
15.14 Conguration record
Please keep your questions to the hotline ready!
Hotline: +49 (5 11) 8 77-14 71
Fax: +49 (5 11) 8 77-16 30
Function Adjustment range Factory setting* Set value
Creep distance Open 0...100 mm 30 mm mm
Cutter distance Open 0...100 mm 30 mm mm
Creep distance Close 0...100 mm 20 mm mm
Cutter distance Close 0...100 mm 40 mm mm
Maximum speed Open 100... 650 mm/s 650mm/s mm/s
Creep speed Open 30... 90 mm/s 40 mm/s mm/s
Cutter speed Open 30... 90 mm/s 60 mm/s mm/s
Initial speed Open 30... 90 mm/s 90 mm/s mm/s
Maximum speed Close 100... 500 mm/s 319 mm/s mm/s
Creep speed Close 30... 90 mm/s 60 mm/s mm/s
Cutter speed Close 30... 90 mm/s 40 mm/s mm/s
Initial speed Close 30... 90 mm/s 90 mm/s mm/s
Nudge speed Close 50... 250 mm/s 150 mm/s mm/s
Acceleration incline OPEN 300... 1400 mm/s
2
1300 mm/s
2
mm/s
2
Braking incline OPEN 300... 1400 mm/s
2
600 mm/s
2
mm/s
2
Reverse incline OPEN/CLOSE 300... 1400 mm/s
2
1200 mm/s
2
mm/s
2
Acceleration incline CLOSE 300... 1400 mm/s
2
500 mm/s
2
mm/s
2
Braking incline CLOSE 300... 1400 mm/s
2
500 mm/s
2
mm/s
2
Reverse incline CLOSE/OPEN 300... 1400 mm/s
2
850 mm/s
2
mm/s
2
Permanent torque (power) 0... 2,5 A 1,0 A A
Permanent torque (power) 0... 2,5 A 1,0 A A
Cutter push torque 0... 10,0 A 3,0 A A
Opening force static 70... 300 N 300 N N
Closing force static 70... 230 N 90 N N
Cutter force static Close 70... 230 N 90 N N
Nudge force static Close 70... 230 N 90 N N
* These adjustment ranges are valid for motor 3 (30V / 4A, up to 180 kg door weight).
Conguration led Motor (24V / 1.8A, up to 120kg door weight) see page 15.
