BC8001A Installation and Operating Instruction
Page 4/49
2. Performance Parameters
Items Standard
Configurations
Extension
Configurations
Number of detector lines (polarity free) 1 2
Number of field devices 127 254
LCD display 240×128 pixel, back light
Digital I/O’s
Nr. of monitored OC output
(400 to 2K ohms @24VDC)
1
Nr. of monitored inputs 2
Nr. of monitored NAC (1.5A @24VDC) 1
Number of history records 1000
Automapping Yes
AC power input 120/240VAC, 60/50Hz
Regulated DC output
24VDC
Battery-backup Sealed Lead Acid,12VDC,12Ah×2
Upload/download port USB 1.1
Dimensions, in mm 369×266×200（W×H×D）
Weight (excluding battery), in: kg 6.5
Alarm response time <10s
AC fuse capacity 5.0A
Battery fuse capacity 10.0A
Operating temperature 0℃ ～ +49℃
Storage temperature –10℃ ～ +50℃
Relative humidity ≤93%(32±2℃)
Usage place Indoor and dry
3. BC8001A External Structure
