BC8001A Installation and Operating Instruction
Page 7/49
Figure 1 Mounting holes for BC8001A
3. Wiring
Install the wirings to the proper location. Refer to figure 2,3,4.
Note:
1. All wirings must be in accordance with corresponding local code or regulation.
2. All wires are UL recognized.
3. All circuits are power limited to NFPA 70.
Caution!
Observe positive and negative poles!
Make sure NO SHORT TO GND and NO SHORT CIRCUIT when connection!
Power limited and Non-Power limited wiring should be separated.
