Display design:
a Present access levels:
- No symbol: No level
- 1:a key: basic access level (Password enter: 1000)
- 2:a key: normal access level (Password enter: 2000)
- 3:e key: technical access level
b Title of displayed pages.
c 7: Number of the selected line; 9: Total number of lines on page.
d Page includes additional lines above, visible when you scroll upward.
e Page includes additional lines below, visible when you scroll downward.
f From here you can access another level below.
g Currently selected line.
Fan control
Extract air fan
Act.fan stage
Fire functio n
Off
Off
Stop
O verru n.clg.elh
Block stage 2/3
Fan stage nightop
S e t.o p.t im e
180 sec
-40.0 °C
Stage 1
a
d
e
f
g
b c
Extr. air fan Off
On navigation lines, the object is highlighted in black when selected. It displays the
present value for a component in front of the navigation arrow.
Navigation:
●● Select line: Turn the navigation dial.
●● Switch to level below: Press the navigation dial.
Act.fan stage Off
The object is also highlighted in black when selected for display lines (read only). It
displays the present value for a component.
Fan stag night op Stage 1
The parameter name and its present value are highlighted against a black
background.
To set a value:
●● Select the line: Turn the navigation dial.
●● To switch setting page: Press the navigation dial.
●● Set the parameter value on setting page: Turn the navigation dial.
●● Exit the setting page and assume the changed parameter value: Press the
navigation dial.
●● Exit setting page without assuming changed parameter value: Press ESC
Display screen
Navigation lines
Display line
Setting line
Short Manual for Climatix Control System [v. 2.14.10, 2.14.20, 2.14.30 & 2.14.40]
SMCX.130215.02GB Page 5
