Siemens CP 443-1 User Manual

5 Performance Data
B4A−39
CP 443-1 Advanced for Industrial Ethernet / Manual Part B4A
Release 01/2007
C79000-G8976-C193-06
Structure of the File System of the CP 443-1 Advanced as Shipped
If you open the system page “Server Information”, the file system of the
CP 443-1 Advanced appears as follows:
Storage location in the file
system
Figure 5-1
Note on Figure 5-1:
For the latest information on the configuration limits, refer to the table on page
B4A−40 or the current system page of your CP.
Meaning of the Memory Areas
On the CP 443-1 Advanced, the file system is divided into 3 areas:
S Flash Area in the C-PLUG (non-volatile memory):
The flash area allows data to be stored and retained if there is a power down.
Since the number of times it is possible to write to this area is restricted, you
should avoid repetitive write operations to this area, when such operations are
necessary, write to RAM.
