7 Using the CP 443−1 Advanced with PROFINET CBA
B4A−50
CP 443-1 Advanced for Industrial Ethernet / Manual Part B4A
Release 01/2007
C79000-G8976-C193-06
Step Explanation / Meaning
1. Downloading the user program and configuration data to the S7−400 station with
STEP 7.
2. Downloading the interconnection information of the process inputs and process
outputs to the PROFINET CBA components over the Ethernet port with SIMATIC
iMap.
Note
When you reload user program blocks, data consistency is only guaranteed if the
CPU is first changed to STOP.
Caution
If problems occur while downloading interconnections from SIMATIC iMap, for
example power down on the target station, it is not always possible to download
the interconnections again when the power returns.
If this error occurs, SIMATIC iMap reports the station as being unreachable.
Remedy:
Using the module switch or the PG command, change the CP 443−1 Advanced
from STOP to RUN to bring the target station back an operational status and to
allow the interconnections to be downloaded again from SIMATIC iMap.
Device Diagnostics in SIMATIC iMap
In online view of SIMATIC iMap, you can use diagnostic functions and, for
example, read out device and functional information.
Note
For more detailed information on adopting the configuration from STEP 7 and use
with PROFINET CBA and the SIMATIC iMap engineering tool, refer to the
documentation on SIMATIC iMap.
