Siemens CPU 1512SP-1 PN User Manual

Article number 6ES7512-1DM03-0AB0
–
MRP interconnection, supported Yes; as MRP ring node according to IEC 62439-2
Edition 3.0
–
MRPD Yes; Requirement: IRT
–
Switchover time on line break, typ. 200ms; For MRP, bumpless for MRPD
–
Number of stations in the ring, max. 50
SIMATIC communication 
•
PG/OP communication Yes; encryption with TLS V1.3 pre-selected
•
S7 routing Yes
•
Data record routing Yes
•
S7 communication, as server Yes
•
S7 communication, as client Yes
•
User data per job, max. See online help (S7 communication, user data
size)
Open IE communication 
•
TCP/IP Yes
–
Data length, max. 64kbyte
–
several passive connections per port,
supported
Yes
•
ISO-on-TCP (RFC1006) Yes
–
Data length, max. 64kbyte
•
UDP Yes
–
Data length, max. 2kbyte; 1 472 bytes for UDP broadcast
–
UDP multicast Yes; max. 78 multicast circuits
•
DHCP Yes
•
DNS Yes
•
SNMP Yes
•
DCP Yes
•
LLDP Yes
•
Encryption Yes; Optional
Web server 
•
HTTP Yes; Standard and user pages
•
HTTPS Yes; Standard and user pages
OPC UA 
•
Runtime license required Yes; "Small" license required
•
OPC UA Client Yes; Data Access (registered Read/Write), Method
Call
–
Application authentication Yes
–
Security policies Available security policies: None, Basic128Rsa15,
Basic256Rsa15, Basic256Sha256
–
User authentication "anonymous" or by user name & password
35
Technical specifications
CPU 1512SP-1 PN (6ES7512-1DM03-0AB0)
Equipment Manual, 11/2022, A5E33591411-AE
