Cycle and reaction times
5.3 Response time
CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
5-17
Calculation
The (longest) response time is the sum of:
Table 5-11 Formula: Longest response time
2 x process image transfer time for the inputs
+ 2 x process image transfer time for the outputs
+ 2 x program processing time
+ 2 × operating system processing time
+ 2 x program processing time
+ 4 x PROFINET IO update time (only if PROFINET IO is used.)
+ 4 x DP cycle time on PROFIBUS DP (only if PROFIBUS DP is used.)
+ I/O delay
= Longest response time
Equivalent to the sum of 2 x the cycle time + I/O delay time + 4 x times the PROFINET IO
update time or 4 x times the DP cycle time on PROFIBUS DP
See also
Overview (Page 5-13)
5.3.4 Reducing the response time with direct I/O access
Reducing the response time
You can reach faster response times with direct access to the I/O in your user program, e.g.
with
• L PIB or
• T PQW
you can partially avoid the response times described above.
Note
You can also achieve fast response times by using process interrupts.
See also
Shortest response time (Page 5-15)
Longest response time (Page 5-16)

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
