Siemens CPU 313C User Manual

Technical data of CPU 31x
7.6 CPU 317-2 DP
CPU 31xC and CPU 31x, Technical Data
7-26 Manual, 01/2006 Edition, A5E00105475-06
Technical data
Weight 460 g
Voltages, currents
Power supply (rated value) DC 24 V
• Permissible range
20.4 V to 28.8 V
Current consumption (no-load operation) 100 mA
Making current Typically 2.5 A
I
2
t Min. 1 A
2
s
External fusing of power supply lines
(recommended)
Min. 2 A
Power loss Typically 3.5 W
7.6 7.6 CPU 317-2 DP
Technical Data
Table 7-7 Technical data for the CPU 317-2 DP
Technical Data
CPU and version
Order number 6ES7317-2AJ10-0AB0
• Hardware version
01
• Firmware version
V 2.1.0
• Associated programming package
STEP 7 as of V 5.2 + SP 1
Memory
RAM
• Integrated
512 KB
• Expandable
No
Capacity of the retentive memory for retentive
data blocks
Max. 256 KB
Load memory Plugged in with MMC (Max. 8 MB)
Buffering Guaranteed by MMC (maintenance-free)
Data storage life on the MMC
(following final programming)
At least 10 years
Execution times
Processing times of
• Bit operations
0.05 μs
• Word instructions
0.2 μs
• Fixed-point arithmetic
0.2 μs
• Floating-point arithmetic
1.0 μs
Timers/counters and their retentivity
S7 counters 512

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
