Siemens CPU 313C User Manual

Technical data of CPU 31xC
6.6 Technical data of the integrated I/O
CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
6-51
Technical data
Connection of signal generators
• For voltage measurement
possible
• For current measurement
– as 2-wire measuring transducer
– as 4-wire measuring transducer
Possible, with external power supply
possible
• for measuring resistance
– with 2-conductor terminal
– with 3-wire connection
– with 4-wire connection
Possible, without compensation of
cable resistance
Not possible
Not possible
Linearization of the characteristics trend By software
• For resistance thermometers
Pt 100
Temperature compensation No
Technical unit for temperature measurement Degrees Celsius/Fahrenheit/Kelvin
6.6.9 Analog outputs
Introduction
This chapter contains the specifications for digital outputs of CPUs 31xC.
The table includes the following CPUs:
• CPU 313C
• CPU 314C-2 DP
• CPU 314C-2 PtP
Technical data
Table 6-15 Technical data of analog outputs
Technical data
Module-specific data
Number of outputs 2
Cable length
• Shielded
Max. 200 m
Voltage, currents, potentials
Rated load voltage L+ 24 VDC
• Polarity reversal protection
Yes
Electrical isolation
• Between channels and the backplane bus
Yes
• Between the channels
No

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
