Siemens CPU 313C User Manual

CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
7-1
Technical data of CPU 31x
7
7.1 7.1 General technical data
7.1.1 Dimensions of CPU 31x
Each CPU features the same height and depth, only the width dimensions differ.
• Height: 125 mm
• Depth: 115 mm, or 180 mm with opened front cover.



Figure 7-1 Dimensions of CPU 31x

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
