Technical data of CPU 31x
7.3 CPU 314
CPU 31xC and CPU 31x, Technical Data
7-8 Manual, 01/2006 Edition, A5E00105475-06
7.3 7.3 CPU 314
Technical data for the CPU 314
Table 7-4 Technical data for the CPU 314
Technical data
CPU and version
Order no. [MLFB] 6ES7314-1AF11-0AB0
• Hardware version
01
• Firmware version
V 2.0.0
• Associated programming package
STEP 7 as of V 5.1 + SP 4
Memory
Work memory
• Integrated
64 Kbytes
• Expandable
No
Load memory Plugged in with MMC (Max. 8 MB)
Data storage life on the MMC
(following final programming)
At least 10 years
Buffering Guaranteed by MMC (maintenance-free)
Execution times
Processing times of
• Bit insructions
Min. 0.1 μs
• Word instructions
Min. 0.2 μs
• Fixed-point arithmetic
Min. 2.0 μs
• Floating-point maths
Min. 3 μs
Timers/counters and their retentive address areas
S7 counters 256
• Retentive address areas
Configurable
• Default
From C0 to C7
• Counting range
0 to 999
IEC Counters Yes
• Type
SFB
• Number
unlimited (limited only by RAM size)
S7 timers 256
• Retentive address areas
Configurable
• Default
Not retentive
• Timer range
10 ms to 9990 s
IEC timers Yes
• Type
SFB
• Number
unlimited (limited only by RAM size)

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
