Technical data of CPU 31xC
6.3 CPU 313C
CPU 31xC and CPU 31x, Technical Data
6-12 Manual, 01/2006 Edition, A5E00105475-06
Technical data
• S7 basic communication
– Reserved (default)
– Configurable
Max. 4
4
From 0 to 4
Routing No
interfaces
1st interface
Type of interface Integrated RS485 interface
Physics RS 485
electrically isolated No
Interface power supply
(15 to 30 VDC)
Max. 200 mA
Functionality
• MPI
Yes
• PROFIBUS DP
No
• PtP communication
No
MPI
Services
• PG/OP communication
Yes
• Routing
No
• Global data communication
Yes
• S7 basic communication
Yes
• S7 communication
– As server
– As client
Yes
No (but with CP and loadable FB)
• Transmission rates
Max. 187.5 kbps
Programming
Programming language LAD/FBD/STL
Instruction set see the Instruction List
Nesting levels 8
System functions (SFC) see the Instruction List
System function blocks (SFB) see the Instruction List
User program protection Yes
Integrated I/O
• Default addresses of the integrated
– Digital inputs
– Digital outputs
– Analog inputs
– Analog outputs
124.0 to 126.7
124.0 to 125.7
752 to 761
752 to 755
Integrated functions
Counters 3 channels (see manual Technological Functions )
Frequency counter 3 channels up to Max. 30 kHz (see the
Technological Functions manual)
Pulse outputs 3 channels pulse-width modulation up to Max.
2,5 kHz (see
Technological Functions manual)

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
