Technical data of CPU 31xC
6.4 CPU 313C-2 PtP and CPU 313C-2 DP
CPU 31xC and CPU 31x, Technical Data
6-20 Manual, 01/2006 Edition, A5E00105475-06
Technical data
CPU 313C-2 PtP CPU 313C-2 DP
Integrated "Controlling" SFB PID controller (see the
Technological Functions
manual)
Dimensions CPU 313C-2 PtP CPU 313C-2 DP
Mounting dimensions W x H x D (mm) 120 x 125 x 130
Weight approx. 566 g
Voltages, currents CPU 313C-2 PtP CPU 313C-2 DP
Power supply (rated value) DC 24 V
Permitted range
20.4 V to 28.8 V
Current consumption (no-load operation) Typically 100 mA
Making current typ. 11 A
Power consumption (nominal value) 700 mA 900 mA
I
2
t 0,7 A
2
s
External fusing of power supply lines
(recommended)
LS switch type B: min. 4 A, type C: min. 2 A
Power loss Typically 10 W
Reference
In Chapter
Specifications of the integrated I/O
are found
under
Digital inputs of CPUs 31xC
and
Digital outputs of CPUs 31xC
the technical data of
integrated I/Os.
the block diagrams of the integrated I/Os under
Arrangement and usage of integrated
I/Os
.
