Communication
3.2 Communication services
CPU 31xC and CPU 31x, Technical Data
3-14 Manual, 01/2006 Edition, A5E00105475-06
Routing: Example of a TeleService application
The figure below shows the example of an application for remote maintenance of an S7
station using a PG. The connection to other subnets is here established via modem
connection.
The lower section of the figure shows how to configure this in STEP 7.
3*
3*
'3PDVWHU
6XEQHW
HJ03,
6XEQHW
HJ352),%86'3
0RGHP
6XEQHW
HJ03,
6XEQHW
HJ352),%86'3
'3VODYH
7HOH6HUYLFH
DGDSWHU
HJ[&'3
HJ[&'3
0RGHP
5HDOLQVWDOODWLRQ
&RQILJXUDWLRQLQ67(3
'3PDVWHU
'3VODYH
HJ&38[&'3
HJ&38[&'3

Siemens CPU 313C Specifications

General

MPI Interface	Yes
Number of digital inputs	24
Number of digital outputs	16
Number of analog inputs	4
Number of analog outputs	2
Supply voltage	24 V DC
High-speed counters	Yes
Bit Operations Execution Time	0.1 µs
Word Operations Execution Time	0.2 µs
Power Consumption	5 W
Dimensions (W x H x D)	40 x 125 x 130 mm
Operating Temperature	0 to 60 °C
Communication Interfaces	MPI
Programming Languages	LAD, FBD, STL
Product type designation	CPU 313C
Weight	490 g
