3.8 Frying Sensor
In the previous project, only the 210 mm inductor had this function.
Now, this function is available in the following inductors:
145 mm, although with only one NTC. To activate the
frying function, a jumper (“bridge”) is needed connected
to the ELIN on the 3-way connector. See inductors.
180 mm, with two NTCs with polarity. The external NTC
is the one which controls the frying function and has a 3-
way connector, although with two wires. And the internal
one has a 2-way connector.
210 mm, with two NTCs with polarity.
In order to guarantee correct operation, the recommended
accessory is needed; it is not included with the device. See items
for induction and recommendations.
In case the recommended pans are not used, safety is guaranteed
(maximum temperature reached 250 ºC), but it is possible that:
Times until reaching the desired temperature may increase.
Overheating may occur in the pan and the food may burn.
The heat may be lower than that programmed and the result of
the cooking may not be ideal.
3.8.1 Components
3.8.1.1 2 NTCs, except the 145 mm inductor
In this case, the inductors on the right are the ones which
have the frying sensor function.
There are two temperature sensors for a more precise control.
