206_58300000141095_ara_en_k.doc – 04.10.a Seite 93 von 113
5.16 Check of residual heat indication
We have two levels which indicate residual heat:
“h” for lower temperatures or operating times
“H” for higher temperatures or longer operating times.
Warning!
Avoid touching the cooking zone showing this indication.
5.16.1 Induction zones
The h/H remain lit while they are above certain temperature values.
The temperature is measured by the NTC of the inductor and it is the
ELIN which transfers the value to the touch Control.
The residual heat indication doesn’t appear while the zone is giving
power. It only appears when the zone is not working or when there is
no pan above.
The indication is programmed to appear in the cooling curve after a
heating upper 100 ºC.
It can be measured above the glass ceran with a temperature
sensor for surfaces with the following spare part number.
Spare part number 341176 Spare part number 340961
