206_58300000141095_ara_en_k.doc – 04.10.a Seite 86 von 113
5.13 Check: low sensitivity on the TouchControl Slider
5.13.1 Problem
Poor sensitivity when touching the slider. It must be pressed for longer
and the reaction is very slow.
5.13.2 Cause
The design of the slider with metal pins is not optimum. They may be
pressed down when used without breaking the slider.
Once the slider is in a lower position to the glass, sensitivity is
decreased.
Top-down view
Front view
5.13.3 Solution
Warning!
Carefully try to pull the metal pins upwards.
In the event that this does not improve sensitivity, order a new part
and take care when handling it.
