3.10.5 Connection between ELINS
3.10.5.1 3I, 5I: 16-way connector
This is a 16-way connector.
Care should be taken upon dismounting it, as it could be damaged.
In case of bad connection, check the connector pins; they may be
slightly bent.
3.10.5.2 Other models: 8-way connector
3.10.6 Superbooster Connection
This is the lower white connector.
