4.5 Applying standards
Each aspirating hole corresponds to the position of a conventional smoke detector.
1. Check whether the applicable standards have been taken into account
sufficiently before you start to plan and install.
2. Take the movements of air in the room into account.
3. Take the detection area of the aspirating holes into account.
– One aspirating hole monitors an area of between 10m
2
and 60m
2
.
5 m
5 m
Fig. 12: Example: Detection grid with a mesh size of 5m
Planning
Applying standards
4
A6V11783979_en--_a 29 | 48
