8 / 62
BA 5060 EN 04/2011
1. Technical data
1.1 General technical data
The most important technical data are shown on the rating plate. These data and the contractual
agreements between Siemens and the customer for the gear unit determine the limits of its correct use.
(See item 1.2)
①
②
③
④
⑤
⑥
⑦
⑨
⑩
⑪
⑫
⑧
Fig. 1: ATEX Rating plate gear unit
① Company logo ⑧ Speed n
2
② Order number, item, sequence number, ⑨ Oil data
year built (oil type, oil viscosity, oil quantity)
③ Total weight in kg ⑩ Instructions number(s)
④ Special information ⑪ Manufacturer and place of manufacture
⑤ Type, size *) ⑫ Country of origin
⑥ Power rating P
2
in kW or torque T
2
in Nm
⑦ Speed n
1
*) Example
H 2 N V 110
Size 105 ... 112.....................
Fitting position V=Vertical.............
Type of output shaft N=Solid shaft with reinforced bearing........
arrangement
Number of stages
2..........
Gearunit type H=Helical gear unit.............
For specifications for the measuringsurface soundpressure level of the various types of gear unit, please
refer to item 1.3.
For additional technical data refer to the orderspecific gearunit documentation.
