6.1 Extra indication and operating devices
The fire terminal is also provided for indication and operation as is the floor
repeater terminal and floor repeater display although these two offer only restricted
functions.
Fire terminal
The fire terminal is an indication and operating unit without the functionality of a
station. It makes possible all display and operating functions of a Cerberus PRO
fire control panel within a C-WEB network, but does not normally have its own
power unit or emergency power supply. A power unit (70 W) or batteries can also
be used.
FT724 fire terminal
The display and operation are the same as that for a fire control panel
Functions
● Supplied via fire control panel or optional supply
● Separate 24 V supply input, monitored
● Can be networked via C-WEB or Ethernet
● System-wide visibility configurable
Floor repeater terminal / floor repeater display
The FT2010 floor repeater terminal and FT2011 floor repeater display allow for the
decentralized indication of the most important events in the fire detection system
and limited operation. Both devices can be connected to the C-NET directly as line
devices. The power is supplied via the C-NET or through an external power unit (if
supplied externally, the voltage source does not need to be electrically isolated)
Floor repeater terminal FT2010
The following indications and operations are possible on the floor repeater
terminal:
Display
● Alarm and fault messages of connected station(s)
● Activated remote transmission (RT)
Operation
● Acknowledge (start investigation time)
● Reset
● Scroll in event lists
● Deactivate buzzer
● Four freely programmable keys
Floor repeater display FT2011
The following indications and operations are possible on the floor repeater
display:
Display
● Alarm and fault messages of connected station(s)
Operation
● Scroll in event lists
● Deactivate buzzer
