Siemens LME7 Series Technical Instructions

LME Series Technical Instructions
Document No. LME-1000
SCC Inc. Page 9 Section 8
Modbus Mapping
ADDRESS
ACCESS
DESCRIPTION
FORMAT
NOTES
27 bit 2
R
INCREASE MODULATION (LR
-
OPEN)
Boolean
TERMINAL X5.03.3
27 bit 3
R
DECREASE MODULATION (LR
-
CLOSED)
Boolean
TERMINAL X5.03.2
27 bit 4
R
COMBUSTION AIR
SWITCH (LP)
Boolean
TERMINAL X3.02.1
27 bit 5
R
LOW GAS PRESSURE SWITCH (Pmin)
Boolean
TERMINAL X5.01.2
27 bit 6
R
RESET BUTTON LME
Boolean
27 bit 7
R
RESET TERMINAL (EK2)
Boolean
TERMINAL X2.03.1
27 bit 8
R
ACTUATOR FEEDBACK (SA
-
R)
Boolean
TERMINAL X2.09.4
27 bit 9
R
SAFETY LIMIT (SK)
Boolean
TERMINAL X3.04.1
27 bit 10
R
CONTROL SWITCH (ON/OFF)
Boolean
TERMINAL X5.03.1
27 bit 11
R
INPUT CAMS (SA
-
ZL)
Boolean
TERMINAL X2.09.8
50
R
PRODUCT ID
String
60
R
BURNER ID
String
70
R
OEM PRODUCT ID
String
80
R
PME PRODUCT ID
String
90
RW
OCI PRODUCT ID
String
WRITABLE DATA AREA
100
R
CURRENT ERROR CODE
Unsigned Int 16
101
R
CURRENT ERROR STARTUPS
Unsigned Int 32
103
R
CURRENT ERROR PHASE
Unsigned Int 32
PHASE IS 0 WHEN NO ERROR
104
R
CURRENT ERROR LOAD
Unsigned Int 16
255 IS NO LOAD RECORDED
110
R
HISTORY 1 ERROR CODE
Unsigned Int 16
111
R
HISTORY 1 ERROR STARTUPS
Unsigned Int 32
113
R
HISTORY 1 ERROR PHASE
Unsigned Int 32
PHASE IS 0 WHEN NO ERROR
114
R
HISTORY 1 ERROR LOAD
Unsigned Int 16
255 IS NO LOAD RECORDED
120
R
HISTORY 2 ERROR CODE
Unsigned Int 16
121
R
HISTORY 2 ERROR STARTUPS
Unsigned Int 32
123
R
HISTORY 2 ERROR PHASE
Unsigned Int 32
PHASE IS 0 WHEN NO ERROR
124
R
HISTORY 2 ERROR LOAD
Unsigned Int 16
255 IS NO LOAD RECORDED
130
R
HISTORY 3 ERROR CODE
Unsigned Int 16
131
R
HISTORY 3 ERROR STARTUPS
Unsigned Int 32
133
R
HISTORY 3 ERROR PHASE
Unsigned Int 32
PHASE IS 0 WHEN NO ERROR
134
R
HISTORY 3 ERROR LOAD
Unsigned Int 16
255 IS NO LOAD RECORDED
140
R
HISTORY 4 ERROR CODE
Unsigned Int 16
141
R
HISTORY 4 ERROR STARTUPS
Unsigned Int 32
143
R
HISTORY 4 ERROR PHASE
Unsigned Int 32
PHASE IS 0 WHEN NO ERROR
144
R
HISTORY 4 ERROR LOAD
Unsigned Int 16
255 IS NO LOAD RECORDED
150
R
HISTORY 5 ERROR CODE
Unsigned Int 16
151
R
HISTORY 5 ERROR STARTUPS
Unsigned Int 32
153
R
HISTORY 5 ERROR PHASE
Unsigned Int 32
PHASE IS 0 WHEN NO ERROR
154
R
HISTORY 5 ERROR LOAD
Unsigned Int 16
255 IS NO LOAD RECORDED
160
R
HISTORY 6 ERROR CODE
Unsigned Int 16
161
R
HISTORY 6 ERROR STARTUPS
Unsigned Int 32
163
R
HISTORY 6 ERROR PHASE
Unsigned Int 32
PHASE IS 0 WHEN NO ERROR
164
R
HISTORY 6 ERROR LOAD
Unsigned Int 16
255 IS NO LOAD RECORDED
170
R
HISTORY 7 ERROR CODE
Unsigned Int 16
171
R
HISTORY 7 ERROR STARTUPS
Unsigned Int 32
173
R
HISTORY 7 ERROR PHASE
Unsigned Int 32
PHASE IS 0 WHEN NO ERROR
