Siemens LME7 Series Technical Instructions

LME Series Technical Instructions
Document No. LME-1000
SCC Inc. Page 11 Section 8
BACnet Mapping
ADDRESS
DESCRIPTION
UNITS
ACTIVE TEXT
INACTIVE TEXT
AV1
PHASE
NO UNITS
--
--
AV2
FLAME INTENSITY
PERCENT
--
--
AV3
MAINS VOLTAGE
VOLTS
--
--
AV4
STARTUPS RESETTABLE
NO UNITS
--
--
AV5
STARTUPS TOTAL
NO UNITS
--
--
AV6
RELAY K12 CYCLES
NO UNITS
--
--
AV7
RELAY K11 CYCLES
NO UNITS
--
--
AV8
RELAY K2 CYCLES
NO UNITS
--
--
AV9
RELAY K1 CYCLES
NO UNITS
--
--
AV10
MAX RELAY CYCLES
NO UNITS
--
--
AV11
CURRENT OUTPUT PERCENT
PERCENT
--
--
AV12
ACTUATOR ACTUAL PERCENT
PERCENT
--
--
AV13
ACTUATOR TARGET PERCENT
PERCENT
--
--
AV14
EXT LOAD CONTROLLER PERCENT
PERCENT
--
--
AV15
FAN SPEED RPM
RPM
--
--
AV16
FAN SPEED PERCENT
PERCENT
--
--
AV17
TARGET FAN SPEED PERCENT
PERCENT
--
--
AV18
PWM SIGNAL PERCENT
PERCENT
--
--
AV19
CURRENT ERROR CODE
NO UNITS
--
--
AV20
CURRENT ERROR STARTUPS
NO UNITS
--
--
AV21
CURRENT ERROR PHASE
NO UNITS
--
--
AV22
CURRENT ERROR LOAD
PERCENT
--
--
AV23
HISTORY
1 ERROR CODE
NO UNITS
--
--
AV24
HISTORY 1 ERROR STARTUPS
NO UNITS
--
--
AV25
HISTORY 1 ERROR PHASE
NO UNITS
--
--
AV26
HISTORY 1 ERROR LOAD
PERCENT
--
--
AV27
HISTORY 2 ERROR CODE
NO UNITS
--
--
AV28
HISTORY 2 ERROR STARTUPS
NO UNITS
--
--
AV29
HISTORY 2 ERROR PHASE
NO UNITS
--
--
AV30
HISTORY 2 ERROR LOAD
PERCENT
--
--
AV31
HISTORY 3 ERROR CODE
NO UNITS
--
--
AV32
HISTORY 3 ERROR STARTUPS
NO UNITS
--
--
AV33
HISTORY 3 ERROR PHASE
NO UNITS
--
--
AV34
HISTORY 3 ERROR LOAD
PERCENT
--
--
AV35
HISTORY 4 ERROR CODE
NO UNITS
--
--
AV36
HISTORY 4 ERROR STARTUPS
NO UNITS
--
--
AV37
HISTORY 4 ERROR PHASE
NO UNITS
--
--
AV38
HISTORY 4 ERROR LOAD
PERCENT
--
--
AV39
HISTORY 5 ERROR CODE
NO UNITS
--
--
AV40
HISTORY 5 ERROR STARTUPS
NO UNITS
--
--
AV41
HISTORY 5 ERROR PHASE
NO UNITS
--
--
AV42
HISTORY 5 ERROR LOAD
PERCENT
--
--
AV43
HISTORY 6 ERROR CODE
NO UNITS
--
--
AV44
HISTORY 6 ERROR STARTUPS
NO UNITS
--
--
AV45
HISTORY 6 ERROR PHASE
NO UNITS
--
--
