Siemens LME7 Series Technical Instructions

Technical Instructions LME Series
Document No. LME-1000
Section 8 Page 12 SCC Inc.
BACnet Mapping
ADDRESS
DESCRIPTION
UNITS
ACTIVE TEXT
INACTIVE TEXT
AV46
HISTORY 6 ERROR LOAD
PERCENT
--
--
AV47
HISTORY 7 ERROR CODE
NO UNITS
--
--
AV48
HISTORY 7 ERROR STARTUPS
NO UNITS
--
--
AV49
HISTORY 7 ERROR PHASE
NO UNITS
--
--
AV50
HISTORY 7 ERROR LOAD
PERCENT
--
--
AV51
HISTORY 8 ERROR CODE
NO UNITS
--
--
AV52
HISTORY 8 ERROR STARTUPS
NO UNITS
--
--
AV53
HISTORY 8 ERROR PHASE
NO UNITS
--
--
AV54
HISTORY 8 ERROR LOAD
PERCENT
--
--
AV55
HISTORY 9 ERROR CODE
NO UNITS
--
--
AV56
HISTORY 9 ERROR STARTUPS
NO UNITS
--
--
AV57
HISTORY 9 ERROR PHASE
NO UNITS
--
--
AV58
HISTORY 9 ERROR LOAD
PERCENT
--
--
AV59
HISTORY 10 ERROR CODE
NO UNITS
--
--
AV60
HISTORY 10 ERROR STARTUPS
NO UNITS
--
--
AV61
HISTORY 10 ERROR PHASE
NO UNITS
--
--
AV62
HISTORY 10 ERROR LOAD
PERCENT
--
--
BV1
SAFETY LIMIT (SK)
LME71/73
--
CLOSED
OPEN
BV2
SAFETY LIMIT (SK)
LME75
--
CLOSED
OPEN
BV3
PROOF OF CLOSURE (POC)
LME71/73
--
CLOSED
OPEN
BV4
VALVE PROVING ENABLE (LT)
LME75
HIGH GAS PRESS SW (Pmax) LME75
PROOF OF CLOSURE (POC) LME75
--
CLOSED
OPEN
BV5
PRESS SW VALVE PROVING (P LT)
LME71/73
--
CLOSED
OPEN
BV6
PRESS SW VALVE PROVING (P LT)
LME75
--
CLOSED
OPEN
BV7
LOW GAS PRESSURE SWITCH (Pmin)
--
CLOSED
OPEN
BV8
CONTROL SWITCH (ON/OFF)
LME71/73
--
CLOSED
OPEN
BV9
CONTROL SWITCH (ON/OFF)
LME75
--
CLOSED
OPEN
BV10
COMBUSTION AIR SWITCH (LP)
LME71/73
--
CLOSED
OPEN
BV11
COMBUSTION AIR SWITCH (LP)
LME75
--
CLOSED
OPEN
BV12
RESET TERMINAL (EK2)
LME71/73
--
CLOSED
OPEN
BV13
RESET TERMINAL (EK2)
LME75
--
CLOSED
OPEN
BV14
INCREASE MODULATION (LR
-
OPEN)
--
CLOSED
OPEN
BV15
DECREASE MODULATION (LR
-
CLOSED)
--
CLOSED
OPEN
BV16
RESET BUTTON LME
--
CLOSED
OPEN
BV17
INPUT CAMS (SA
-
ZL)
LME75
--
CLOSED
OPEN
BV18
FLAME PRESENT
--
FLAME
NO FLAME
BV19
ALARM (AL)
--
ALARM
NO ALARM
BV20
NO COMM TO LME
--
OK
NO COMM
BV21
ACTUATOR FEEDBACK (SA
-
R)
--
CLOSED
OPEN
BV22
SAFETY VALVE (SV)
--
CMD ON
CMD OFF
BV23
ACTUATOR LOW
-
FIRE (SA
-
KL)
--
CMD ON
CMD OFF
BV24
ACTUATOR HIGH
-
FIRE (SA
-
NL)
--
CMD ON
CMD OFF
BV25
PILOT VALVE (PV)
--
CMD ON
CMD OFF
BV26
IGNITION (Z)
--
CMD ON
CMD OFF
