LME Series Technical Instructions
Document No. LME-1000
SCC Inc. Page 1 Section 1
Introduction
The LME7 burner control is ideally suited for use in industrial thermal process applications. The
LME7 is extremely flexible, and encompasses the following features:
• Accepts standard UV, self-check UV, or self-check IR scanners and/or flame rods
• Integral LED display
• Programmable purge times and safety times
• Programmable actuator positions for purge, ignition, and low fire
• Adjustable time overlap of spark ignition and pilot valve
• Adjustable time overlap of pilot and main gas valves
• Proof-of-closure (POC) switch monitoring
• Modbus RTU or BACnet MS/TP communication
• Optional gas valve proving function
• Password-protected access to OEM parameters
• Integrated actuator control
• Integrated PWM blower control
Figure 1-1: The Main Components of an LME7 System
